Description
| Description | 1-Leaf | 2-Leaf |
|---|---|---|
| Clearance Width¹ | 500 – 1500 mm | 1000 – 2400 mm |
| Clearance Height¹ | Max. 3000 mm | Max. 3000 mm |
| Door Leaf Weight | Max. 130 kg / Leaf | Max. 120 kg / Leaf |
| Supply Voltage | 230V AC, 50 Hz | 230V AC, 50 Hz |
| Hold-Open Time | 0 – 60 seconds | 0 – 60 seconds |
| Opening Speed | Max. 0.9 m/s | Max. 0.9 m/s |
| Closing Speed | Max. 0.7 m/s | Max. 0.7 m/s |
| Winter Opening² | 50% – 100% of passage width | 50% – 100% of passage width |
| Protection Class / Ambient Temp | IP22 | IP22 |
¹ Standard dimensions are subject to overall measurement, ratio of height and width, and installation conditions. Special solutions available on request.
² Must comply with mandatory escape route width.
